SSM10N961L - Toshiba

SSM10N961L Details

• Manufacturer Part Number:

  SSM10N961L

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Toshiba America Electronic Components

• Configuration:

  COMMON DRAIN, 2 ELEMENTS WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  30 V

• Drain Current-Max (ID):

  9 A

• Drain-source On Resistance-Max:

  0.0176 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• JESD-30 Code:

  R-XBCC-N10

• Number of Elements:

  2

• Number of Terminals:

  10

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  0.88 W

• Pulsed Drain Current-Max (IDM):

  72 A

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Position:

  BOTTOM

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
