SSM6J505NU,LF - Toshiba

Description: MOSFET P-Ch U-MOS VI FET ID -12A -12V 1200pF

Download SSM6J505NU,LF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
SSM6J505NU,LF - Toshiba - PCB symbol
click to zoom
PCB Footprints
SSM6J505NU,LF - Toshiba PCB footprint - Other - Other - SOT-1220
click to zoom
3D Models
SSM6J505NU,LF - Toshiba - 3D model - Other - SOT-1220
click to zoom

SSM6J505NU,LF Details

  • Manufacturer Part Number:

    SSM6J505NU,LF

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    UDFN6B, 6 PIN

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Toshiba America Electronic Components

  • YTEOL:

    5.4

  • Case Connection:

    DRAIN

  • Configuration:

    SINGLE WITH BUILT-IN DIODE

  • DS Breakdown Voltage-Min:

    12 V

  • Drain Current-Max (ID):

    12 A

  • Drain-source On Resistance-Max:

    0.016 Ω

  • FET Technology:

    METAL-OXIDE SEMICONDUCTOR

  • Feedback Cap-Max (Crss):

    800 pF

  • JESD-30 Code:

    S-PDSO-N6

  • Number of Elements:

    1

  • Number of Terminals:

    6

  • Operating Mode:

    ENHANCEMENT MODE

  • Operating Temperature-Max:

    150 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE

  • Polarity/Channel Type:

    P-CHANNEL

  • Power Dissipation-Max (Abs):

    1.25 W

  • Pulsed Drain Current-Max (IDM):

    30 A

  • Surface Mount:

    YES

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    DUAL

  • Transistor Application:

    SWITCHING

  • Transistor Element Material:

    SILICON

SSM6J505NU,LF Frequently Asked Questions (FAQs)

  • The recommended operating temperature range for SSM6J505NU,LF is -40°C to 150°C.
  • To ensure reliability, it's recommended to follow proper thermal design and layout guidelines, and to consider derating the device's power handling capabilities at high temperatures.
  • The maximum allowable power dissipation for SSM6J505NU,LF is 1.5W, and it's recommended to derate the power handling capabilities based on the operating temperature and other environmental factors.
  • Yes, SSM6J505NU,LF can be used in switching regulator applications, but it's essential to ensure that the device is properly biased and that the switching frequency is within the recommended range.
  • It's recommended to follow proper ESD handling procedures when working with SSM6J505NU,LF, including using ESD-safe workstations, wrist straps, and packaging materials.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

SSM6J505NU,LF Overview

Use the download button to access the SSM6J505NU,LF schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SSM6J, or try a keyword search, such as Power Field-Effect Transistors
