SST12LP14A-QVCE - Microchip

Description: RF Amplifier 2.4-2.5GHz 3.3V 210mA ICC 802.11 b/g

Download SST12LP14A-QVCE Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
SST12LP14A-QVCE - Microchip PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 16-Contact Very-thin Quad Flat No-lead (VQFN) SST Package Code: QVC
click to zoom
3D Models
SST12LP14A-QVCE - Microchip  - 3D model - Quad Flat No-Lead - 16-Contact Very-thin Quad Flat No-lead (VQFN) SST Package Code: QVC
click to zoom

SST12LP14A-QVCE Details

  • Manufacturer Part Number:

    SST12LP14A-QVCE

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    3 X 3 MM, ROHS COMPLIANT, MO-220IVEED, VQFN-16

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.33.00.01

  • Manufacturer:

    Microchip Technology Inc

  • YTEOL:

    0

  • Additional Feature:

    HIGH RELIABILITY

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Gain:

    28 dB

  • Input Power-Max (CW):

    5 dBm

  • JESD-609 Code:

    e3

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Frequency-Max:

    2485 MHz

  • Operating Frequency-Min:

    2400 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    LCC16,.12SQ,20

  • Power Supplies:

    3.3 V

  • RF/Microwave Device Type:

    NARROW BAND MEDIUM POWER

  • Supply Current-Max:

    230 mA

  • Surface Mount:

    YES

  • Technology:

    GAAS

  • Terminal Finish:

    Matte Tin (Sn)

  • VSWR-Max:

    2

SST12LP14A-QVCE Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for SST12LP14A-QVCE is 1.65V to 3.6V, with a typical voltage of 3.3V.
  • To ensure reliable data retention, it's essential to follow the recommended storage conditions, such as storing the device in a cool, dry place, away from direct sunlight, and avoiding exposure to extreme temperatures, humidity, or radiation.
  • The SST12LP14A-QVCE supports a maximum clock frequency of 104 MHz.
  • No, the SST12LP14A-QVCE is not designed to operate at 5V. It's recommended to use a voltage regulator or level shifter to ensure the device operates within its recommended voltage range.
  • It's essential to follow the recommended power-up and power-down sequencing to prevent damage to the device. Typically, the power supply should be applied before the clock signal, and the clock signal should be stable before accessing the device.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

SST12LP14A-QVCE Overview

Use the download button to access the SST12LP14A-QVCE schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SST12, or try a keyword search, such as RF/Microwave Amplifiers
