ST8L60N065DM9 - STMicroelectronics

ST8L60N065DM9 Details

• Manufacturer Part Number:

  ST8L60N065DM9

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  STMicroelectronics

• YTEOL:

  10

• Additional Feature:

  BULK: 3000

• Avalanche Energy Rating (Eas):

  360 mJ

• Case Connection:

  DRAIN

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  600 V

• Drain Current-Max (ID):

  39 A

• Drain-source On Resistance-Max:

  0.065 Ω

• FET Technology:

  SUPERJUNCTION MOSFET

• JESD-30 Code:

  S-PSSO-N4

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  4

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  202 W

• Pulsed Drain Current-Max (IDM):

  143 A

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  NO LEAD

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
