STDRIVEG600W - STMicroelectronics

STDRIVEG600W Details

• Manufacturer Part Number:

  STDRIVEG600W

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DIE

• Country Of Origin:

  Italy

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  20 Weeks

• Manufacturer:

  STMicroelectronics

• YTEOL:

  6

• High Side Driver:

  YES

• Input Characteristics:

  SCHMITT TRIGGER

• Interface IC Type:

  HALF BRIDGE BASED MOSFET DRIVER

• JESD-30 Code:

  R-XUUC-N

• Number of Functions:

  1

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Characteristics:

  OPEN-DRAIN

• Output Peak Current Limit-Nom:

  6 A

• Output Polarity:

  TRUE

• Package Body Material:

  UNSPECIFIED

• Package Code:

  UUC

• Package Equivalence Code:

  DIE OR CHIP

• Package Shape:

  RECTANGULAR

• Package Style:

  UNCASED CHIP

• Supply Voltage-Max:

  20 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  6 V

• Supply Voltage1-Max:

  20 V

• Supply Voltage1-Min:

  4.4 V

• Supply Voltage1-Nom:

  6 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Position:

  UPPER

• Turn-off Time:

  0.06 µs

• Turn-on Time:

  0.06 µs
