STL47N60M6 - STMicroelectronics

STL47N60M6 Details

• Manufacturer Part Number:

  STL47N60M6

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• Factory Lead Time:

  14 Weeks

• Date Of Intro:

  2019-01-08

• Manufacturer:

  STMicroelectronics

• YTEOL:

  5

• Avalanche Energy Rating (Eas):

  800 mJ

• Case Connection:

  DRAIN

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  600 V

• Drain Current-Max (ID):

  31 A

• Drain-source On Resistance-Max:

  0.082 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  3.7 pF

• JESD-30 Code:

  S-PSSO-N4

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  3

• Number of Elements:

  1

• Number of Terminals:

  4

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  190 W

• Pulsed Drain Current-Max (IDM):

  124 A

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Position:

  SINGLE

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
