STM32WB30CEU5ATR - STMicroelectronics

STM32WB30CEU5ATR Details

• Manufacturer Part Number:

  STM32WB30CEU5ATR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  UFQFPN-48

• ECCN Code:

  5A992.C

• HTS Code:

  8542.31.00.30

• Factory Lead Time:

  13 Weeks

• Date Of Intro:

  2020-07-08

• Manufacturer:

  STMicroelectronics

• YTEOL:

  9

• JESD-30 Code:

  S-XQCC-N48

• Length:

  7 mm

• Number of Terminals:

  48

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -10 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC48,.27SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Seated Height-Max:

  0.6 mm

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  3.3 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  OTHER

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  7 mm

• uPs/uCs/Peripheral ICs Type:

  RFSoC
