STS1005S1V8 - XP POWER

STS1005S1V8 Details

• Manufacturer Part Number:

  STS1005S1V8

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD-10/6

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Date Of Intro:

  2018-07-30

• Manufacturer:

  XP Power

• YTEOL:

  0

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  3 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  R-XDMA-N6

• Length:

  15.2 mm

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  1 A

• Output Voltage-Max:

  1.98 V

• Output Voltage-Min:

  1.62 V

• Output Voltage-Nom:

  1.8 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  DILCC6/10,.47

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  4.1 mm

• Surface Mount:

  YES

• Switcher Configuration:

  BUCK

• Switching Frequency-Max:

  1200 kHz

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  2.52 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  10

• Width:

  11.8 mm
