STTH60RQ06-M2Y - STMicroelectronics

STTH60RQ06-M2Y Details

• Manufacturer Part Number:

  STTH60RQ06-M2Y

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Factory Lead Time:

  53 Weeks, 1 Day

• Manufacturer:

  STMicroelectronics

• YTEOL:

  7.35

• Breakdown Voltage-Min:

  600 V

• Case Connection:

  ISOLATED

• Configuration:

  BRIDGE, 4 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  BRIDGE RECTIFIER DIODE

• Forward Voltage-Max (VF):

  2.95 V

• JESD-30 Code:

  R-PDSO-G9

• Non-rep Pk Forward Current-Max:

  180 A

• Number of Elements:

  4

• Number of Phases:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  30 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Reference Standard:

  AEC-Q101

• Rep Pk Reverse Voltage-Max:

  600 V

• Reverse Current-Max:

  40 µA

• Reverse Recovery Time-Max:

  0.055 µs

• Reverse Test Voltage:

  600 V

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED
