STW55NM60N - STMicroelectronics

STW55NM60N Details

• Manufacturer Part Number:

  STW55NM60N

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  TO-247AC

• Pin Count:

  3

• ECCN Code:

  EAR99

• Manufacturer:

  STMicroelectronics

• YTEOL:

  6.18

• Avalanche Energy Rating (Eas):

  850 mJ

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  600 V

• Drain Current-Max (ID):

  51 A

• Drain-source On Resistance-Max:

  0.06 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  30 pF

• JEDEC-95 Code:

  TO-247AC

• JESD-30 Code:

  R-PSFM-T3

• JESD-609 Code:

  e3

• Number of Elements:

  1

• Number of Terminals:

  3

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  350 W

• Pulsed Drain Current-Max (IDM):

  204 A

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
