STX-3200-5NB-701C - Kycon

STX-3200-5NB-701C Details

• Manufacturer Part Number:

  STX-3200-5NB-701C

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Kycon Inc

• YTEOL:

  7

• Additional Feature:

  94V-0

• Audio Type:

  STEREO

• Board Mounting Option:

  SOLDERABLE RETENTION CLIPS

• Body Depth:

  0.594 inch

• Body Length:

  0.472 inch

• Body/Shell Style:

  JACK

• Configuration:

  1X1 HORIZONTAL

• Connector Type:

  3.5MM AUDIO

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Gender:

  FEMALE

• Contact Material:

  COPPER ALLOY

• Contact Resistance:

  100 mΩ

• Contact Style:

  RND PIN-SKT

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  500VAC V

• Durability:

  5000 Cycles

• IEC Conformance:

  NO

• Insertion Force-Max:

  29.8016 N

• Insulation Resistance:

  100000000 Ω

• Insulator Color:

  BLACK

• MIL Conformance:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Poles:

  5

• Number of Ports:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• Plating Thickness:

  100u inch

• Polarization Key:

  POLARIZED KEY

• Reference Standard:

  UL, CSA

• Terminal Length:

  0.138 inch

• Termination Type:

  SOLDER

• Withdrawl Force-Min:

  3.0024 N
