STX-4335-5BGP-S1 Details

• Manufacturer Part Number:

  STX-4335-5BGP-S1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Kycon Inc

• YTEOL:

  7

• Audio Type:

  STEREO

• Board Mounting Option:

  SOLDERABLE RETENTION CLIPS

• Body Breadth:

  1.457 inch

• Body Depth:

  1.516 inch

• Body Length:

  0.496 inch

• Body/Shell Style:

  JACK

• Configuration:

  3X1 HORIZONTAL

• Connector Type:

  3.5MM AUDIO

• Contact Finish Termination:

  TIN

• Contact Gender:

  FEMALE

• Contact Resistance:

  100 mΩ

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  700VAC V

• Durability:

  1000 Cycles

• Insulation Resistance:

  100000000 Ω

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Poles:

  7

• Number of Ports:

  3

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• Plating Thickness:

  FLASH inch

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  1 A

• Reference Standard:

  UL, CSA

• Shell Finish:

  TIN

• Shell Material:

  STEEL

• Terminal Length:

  0.087 inch

• Termination Type:

  SOLDER
