SVC75C3C07C2-100.000M - Suntsu

SVC75C3C07C2-100.000M Details

• Manufacturer Part Number:

  SVC75C3C07C2-100.000M

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Manufacturer:

  Suntsu Electronics Inc

• Additional Feature:

  TRI-STATE; ENABLE/DISABLE FUNCTION; MIL-STD-202; MIL-STD-883

• Control Voltage-Max:

  3 V

• Control Voltage-Min:

  0.3 V

• Fall Time-Max:

  5 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Deviation/Pullability:

  80 ppm

• Frequency Stability:

  25%

• Linearity:

  10%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Nom:

  100 MHz

• Operating Temperature-Max:

  70 °C

• Oscillator Type:

  CMOS

• Output Load:

  15 pF

• Package Body Material:

  CERAMIC

• Package Equivalence Code:

  DILCC6,.2

• Physical Dimension:

  7.0mm x 5.0mm x 1.7mm

• Rise Time-Max:

  5 ns

• Supply Current-Max:

  25 mA

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %
