SVSA2805D/H+E - VPT

SVSA2805D/H+E Details

• Manufacturer Part Number:

  SVSA2805D/H+E

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-8

• Country Of Origin:

  Taiwan, USA

• ECCN Code:

  EAR99

• Manufacturer:

  VPT Inc

• YTEOL:

  6

• Additional Feature:

  ALSO AVAILABEL OUTPUT VOLTAGE: -5V

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  71%

• Input Voltage-Max:

  50 V

• Input Voltage-Min:

  15 V

• Input Voltage-Nom:

  28 V

• JESD-30 Code:

  S-XDMA-P8

• Length:

  27.31 mm

• Line Regulation-Max:

  0.001%

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  1 A

• Output Voltage-Max:

  5.075 V

• Output Voltage-Min:

  4.925 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  SQUARE

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT

• Qualification Status:

  Not Qualified

• Ripple Voltage (Main Out):

  0.017675 Vrms

• Screening Level:

  MIL-PRF-38534 Class H

• Seated Height-Max:

  6.86 mm

• Surface Mount:

  NO

• Switching Frequency-Max:

  500 kHz

• Technology:

  HYBRID

• Temperature Grade:

  MILITARY

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Dose:

  30k Rad(Si) V

• Total Power Output-Max:

  5 W

• Trim/Adjustable Output:

  NO

• Width:

  27.31 mm
