SW-239 - MACOM

SW-239 Details

• Manufacturer Part Number:

  SW-239

• Rohs Code:

  No

• Part Life Cycle Code:

  Transferred

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  MACOM

• 1dB Compression Point:

  21 dBm

• Additional Feature:

  HIGH ISOLATION

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  34 dBm

• Insertion Loss-Max:

  0.8 dB

• Isolation-Min:

  22 dB

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Number of Terminals:

  8

• On Time-Nom:

  0.004 µs

• Operating Frequency-Max:

  2500 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOP8,.25

• Port Termination:

  ABSORPTIVE

• Power Supplies:

  -5 V

• RF/Microwave Device Type:

  SPDT

• Surface Mount:

  YES

• Technology:

  GAAS

• VSWR-Max:

  1.2
