SW-T2-4B-B-A2-MA2 - Adam Tech

SW-T2-4B-B-A2-MA2 Details

• Manufacturer Part Number:

  SW-T2-4B-B-A2-MA2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Manufacturer:

  Adam Technologies Inc

• YTEOL:

  9.2

• Actuator Angle:

  24 deg

• Actuator Length:

  0.433 inch

• Actuator Material:

  BRASS

• Actuator Type:

  LEVER

• Body Breadth:

  12.7 mm

• Body Color:

  BLACK

• Body Height:

  9.5 mm

• Body Length or Diameter:

  13.2 mm

• Bushing Length:

  0.346 inch

• Bushing Type:

  M6X0.75

• Contact (AC) Max Rating R Load:

  6A@125VAC

• Contact Current(AC)-Max:

  6 A

• Contact Function:

  ON-ON

• Contact Resistance:

  0.02 mΩ

• Contact Voltage(AC)-Max:

  125 V

• Dielectric Withstand Volts:

  1500VAC V

• Electrical Life:

  10000 Cycle(s)

• Housing Material:

  BAKELITE

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  PANEL MOUNT

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  DPDT

• Switch Type:

  TOGGLE SWITCH

• Terminal Length:

  0.248 inch

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
