SY89295UTG - Microchip

SY89295UTG Details

• Manufacturer Part Number:

  SY89295UTG

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  TQFP-32

• Pin Count:

  32

• Manufacturer Package Code:

  TQFP-32

• Country Of Origin:

  Philippines, Thailand

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  9

• Additional Feature:

  ALSO OPERATES WITH 3.3V NOMINAL SUPPLY VOLTAGE

• Family:

  CMOS

• JESD-30 Code:

  S-PQFP-G32

• JESD-609 Code:

  e4

• Length:

  7 mm

• Logic IC Type:

  ACTIVE DELAY LINE

• Moisture Sensitivity Level:

  2

• Number of Functions:

  1

• Number of Taps/Steps:

  1023

• Number of Terminals:

  32

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Polarity:

  COMPLEMENTARY

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TQFP

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, THIN PROFILE

• Packing Method:

  TRAY

• Programmable Delay Line:

  YES

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.2 mm

• Supply Voltage-Max (Vsup):

  3.6 V

• Supply Voltage-Min (Vsup):

  2.375 V

• Supply Voltage-Nom (Vsup):

  2.5 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  QUAD

• Width:

  7 mm
