SYD-20-33+ - Mini-Circuits

Description: Signal Conditioning 20.8 dB SMT Directional Coupler, 30 - 3000 MHz, 50 ohms

Download SYD-20-33+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
SYD-20-33+ - Mini-Circuits PCB footprint - Other - Other - SYD-20-33+-1
click to zoom
3D Models
SYD-20-33+ - Mini-Circuits  - 3D model - Other - SYD-20-33+-1
click to zoom

SYD-20-33+ Details

  • Manufacturer Part Number:

    SYD-20-33+

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    ROHS COMPLIANT, CASE AH202, 8 PIN

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    6.89

  • Characteristic Impedance:

    50 Ω

  • Construction:

    MODULE

  • Input Power-Max (CW):

    30 dBm

  • Insertion Loss-Max:

    2.1 dB

  • JESD-609 Code:

    e4

  • Operating Frequency-Max:

    3000 MHz

  • Operating Frequency-Min:

    30 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • RF/Microwave Device Type:

    DIRECTIONAL COUPLER

  • Terminal Finish:

    Gold (Au) - with Nickel (Ni) barrier

  • VSWR-Max:

    1.2
