SYDC-19-52HP+ - Mini-Circuits

Description: RF Directional Coupler General Purpose 30MHz ~ 512MHz 20dB 8-SMD, No Lead

Download SYDC-19-52HP+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
SYDC-19-52HP+ - Mini-Circuits PCB footprint - Other - Other - AH1647
click to zoom
3D Models
SYDC-19-52HP+ - Mini-Circuits  - 3D model - Other - AH1647
click to zoom

SYDC-19-52HP+ Details

  • Manufacturer Part Number:

    SYDC-19-52HP+

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    6.3

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Input Power-Max (CW):

    46.99 dBm

  • Insertion Loss-Max:

    0.6 dB

  • Operating Frequency-Max:

    512 MHz

  • Operating Frequency-Min:

    30 MHz

  • Operating Temperature-Max:

    65 °C

  • Operating Temperature-Min:

    -40 °C

  • RF/Microwave Device Type:

    BI-DIRECTIONAL COUPLER

  • VSWR-Max:

    2

SYDC-19-52HP+ Frequently Asked Questions (FAQs)

  • Mini-Circuits provides a recommended PCB layout and footprint in their application notes and evaluation board documentation. It's essential to follow these guidelines to ensure optimal performance, especially for high-frequency applications.
  • To achieve the specified isolation and return loss performance, ensure that the device is properly soldered and mounted on a well-designed PCB with adequate grounding and shielding. Additionally, follow the recommended DC biasing and RF signal routing guidelines.
  • While the datasheet specifies an operating temperature range of -40°C to +85°C, it's essential to note that the device's performance may degrade at higher temperatures. For optimal performance, it's recommended to operate the device within a temperature range of -20°C to +70°C.
  • Yes, the SYDC-19-52HP+ can be used in switching applications, but it's essential to consider the device's switching speed, rise/fall times, and power handling capabilities. The device is designed for high-power applications, but it's not suitable for extremely high-speed switching (>100 kHz). Consult with Mini-Circuits' application engineers for specific guidance.
  • The recommended DC biasing scheme for the SYDC-19-52HP+ involves applying a positive voltage to the control pin (Vctrl) and grounding the RF pins. The specific biasing voltage and current requirements can be found in the datasheet or by consulting with Mini-Circuits' application engineers.
