iNRCORE recommends a 4-layer PCB with a dedicated ground plane and thermal vias to dissipate heat. A thermal pad on the bottom of the device should be connected to a large copper area on the PCB to ensure efficient heat dissipation.
iNRCORE recommends following the recommended PCB layout and mounting guidelines, using a secure screw-down or adhesive mounting method, and ensuring the device is properly soldered to the PCB. Additionally, consider using a vibration-dampening material or potting the device for added protection.
Lead time and MOQ may vary depending on the region and distributor. Typically, the lead time is 6-8 weeks, and the MOQ is 100-500 pieces. It's best to check with an authorized distributor or iNRCORE directly for the most up-to-date information.
Yes, the T-330SCT is an ESD-sensitive device. Handle the device with ESD-protective equipment, such as wrist straps and mats, and store it in a static-shielding bag or container to prevent damage.
Yes, the T-330SCT is designed for high-reliability applications. It has undergone rigorous testing and qualification, and its hermetically sealed package ensures long-term stability and performance. However, it's essential to follow proper design, manufacturing, and testing procedures to ensure the device meets the specific application requirements.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
T-330SCT Overview
Use the download button to access the T-330SCT schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like T-330,
or try a keyword search, such as Pulse/Datacom Transformers
