T6650-DLD - COILCRAFT

T6650-DLD Details

• Manufacturer Part Number:

  T6650-DLD

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• ECCN Code:

  EAR99

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  6.65

• Application:

  GATE DRIVE

• ET Product-Min:

  48 V-us

• Height:

  5.46 mm

• Input Voltage-Nom:

  5 V

• Isolation Voltage:

  1500 V

• Length:

  10.16 mm

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TR, EMBOSSED PLASTIC, 13 INCH

• Primary Inductance:

  176 µH

• Surface Mount:

  YES

• Terminal Finish:

  Tin/Silver - Matte Tin - with Nickel barrier

• Transformer Type:

  PULSE TRANSFORMER

• Turns Ratio (Np:Ns):

  1:5

• Width:

  8.75 mm
