TA78L09PF(TE85L,F) - Toshiba

TA78L09PF(TE85L,F) Details

• Manufacturer Part Number:

  TA78L09PF(TE85L,F)

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SON

• Package Description:

  3 X 3 MM, 0.65 MM PITCH, PLASTIC, SON-8

• Pin Count:

  8

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0

• Adjustability:

  FIXED

• Input Voltage-Max:

  24 V

• Input Voltage-Min:

  11.4 V

• JESD-30 Code:

  R-PDSO-F8

• Length:

  2.9 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.09%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Output Voltage1-Max:

  9.36 V

• Output Voltage1-Min:

  8.64 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VSOF

• Package Equivalence Code:

  FL8,.1,25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, VERY THIN PROFILE

• Packing Method:

  TR

• Qualification Status:

  Not Qualified

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR

• Seated Height-Max:

  0.85 mm

• Surface Mount:

  YES

• Technology:

  BIPOLAR

• Terminal Form:

  FLAT

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Width:

  2.4 mm
