TA8176SN - Toshiba

TA8176SN Details

• Manufacturer Part Number:

  TA8176SN

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SIP

• Package Description:

  SSIP-12

• Pin Count:

  12

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0

• Built-in IF Amplifier:

  YES

• Consumer IC Type:

  AUDIO TUNER

• Input Frequency-Max (RF):

  220 MHz

• JESD-30 Code:

  R-PSIP-T12

• Length:

  21.5 mm

• Number of Bands:

  1

• Number of Functions:

  1

• Number of Terminals:

  12

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -25 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SIP

• Package Equivalence Code:

  SIP12,.05,70

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  6.1 mm

• Supply Current-Max:

  23 mA

• Supply Voltage-Max (Vsup):

  14 V

• Supply Voltage-Min (Vsup):

  4 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.778 mm

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  2.8 mm
