TBA2-1222 - Traco Power

TBA2-1222 Details

• Manufacturer Part Number:

  TBA2-1222

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SIP-7/5

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• Manufacturer:

  Traco Power

• YTEOL:

  6.3

• Additional Feature:

  Additional -12V Output also available

• Analog IC - Other Type:

  DC-DC UNREGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  83%

• Input Voltage-Max:

  13.2 V

• Input Voltage-Min:

  10.8 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-PSMA-T5

• JESD-609 Code:

  e3

• Length:

  19.55 mm

• Line Regulation-Max:

  1.5%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  5

• Operating Temperature-Max:

  90 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.08 A

• Output Voltage-Max:

  12.36 V

• Output Voltage-Min:

  11.64 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.088375 Vrms

• Seated Height-Max:

  10.55 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Finish:

  Bright Tin (Sn) - with Nickel (Ni) barrier

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  2 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  0.01 s

• Width:

  7.6 mm
