TC017-N11ABB - Well Buying

TC017-N11ABB Details

• Manufacturer Part Number:

  TC017-N11ABB

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  Well Buying Industrial Co Ltd

• Actuator Material:

  LIQUID CRYSTAL POLYMER

• Actuator Type:

  SHARP FEEL TYPE

• Body Breadth:

  3.4 mm

• Body Height:

  1.62 mm

• Body Length or Diameter:

  4.6 mm

• Circuit Configuration:

  1X1

• Contact Current(DC)-Max:

  0.05 A

• Contact (DC) Max Rating R Load:

  0.05A@12VDC

• Contact Resistance:

  0.5 mΩ

• Contact Voltage(DC)-Max:

  12 V

• Dielectric Withstand Volts:

  250VAC V

• Electrical Life:

  100000 Cycle(s)

• Housing Material:

  STAINLESS STEEL

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  LIQUID CRYSTAL POLYMER

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Switches:

  1

• Operating Force-Max:

  2.059 N

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Solderability:

  REFLOW

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  KEYPAD SWITCH

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
