TC58NVG0S3ETAI0 - Toshiba

TC58NVG0S3ETAI0 Details

• Manufacturer Part Number:

  TC58NVG0S3ETAI0

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  TSOP

• Package Description:

  TSOP-48

• Pin Count:

  48

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.51

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0

• JESD-30 Code:

  R-PDSO-G48

• Length:

  18.4 mm

• Memory Density:

  1073741824 bit

• Memory IC Type:

  FLASH

• Memory Width:

  8

• Number of Functions:

  1

• Number of Terminals:

  48

• Number of Words:

  134217728 words

• Number of Words Code:

  128000000

• Operating Mode:

  ASYNCHRONOUS

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  128MX8

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TSSOP

• Package Equivalence Code:

  TSSOP48,.8,20

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

• Parallel/Serial:

  SERIAL

• Programming Voltage:

  3.3 V

• Seated Height-Max:

  1.2 mm

• Standby Current-Max:

  0.00005 A

• Supply Current-Max:

  0.03 mA

• Supply Voltage-Max (Vsup):

  3.6 V

• Supply Voltage-Min (Vsup):

  2.7 V

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  DUAL

• Type:

  NAND TYPE

• Width:

  12 mm

• Write Cycle Time-Max (tWC):

  0.000025 ms

• Write Protection:

  HARDWARE
