TCM4-452X+ - Mini-Circuits

Description: Surface Mount RF Transformer. 50Ω 20 to 4500 MHz.

Download TCM4-452X+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TCM4-452X+ - Mini-Circuits PCB footprint - Other - Other - TCM4-452X+-1
click to zoom
3D Models
TCM4-452X+ - Mini-Circuits  - 3D model - Other - TCM4-452X+-1
click to zoom

TCM4-452X+ Details

  • Manufacturer Part Number:

    TCM4-452X+

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    CHIP

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    5.5

  • Additional Feature:

    HEIGHT & LENGTH DIM INCLUDES TERMINALS ALSO

  • Cut-off Frequency-Max:

    4500 MHz

  • Cut-off Frequency-Min:

    20 MHz

  • Height:

    4.06 mm

  • Insertion Loss:

    3 dB

  • Length:

    4.06 mm

  • Mounting Feature:

    SURFACE MOUNT

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Packing Method:

    TR, 13 INCH

  • Surface Mount:

    YES

  • Transformer Type:

    RF TRANSFORMER

  • Width:

    3.81 mm

TCM4-452X+ Frequently Asked Questions (FAQs)

  • A good PCB layout and grounding scheme is crucial for optimal performance. Mini-Circuits recommends a multi-layer PCB with a solid ground plane, and to keep the signal traces as short as possible. Additionally, it's recommended to use a common ground point for all components and to avoid running signal traces near the edges of the board.
  • To ensure proper biasing, follow the recommended biasing circuit shown in the datasheet. Make sure to use a stable voltage source and decouple the power supply lines with capacitors. Also, ensure that the bias voltage is within the recommended range (typically 5-15V) and that the current limit is set correctly.
  • The maximum power handling capability of the TCM4-452X+ is typically limited by the device's thermal characteristics. According to the datasheet, the maximum power dissipation is 1.5W. However, it's recommended to derate the power handling capability based on the operating frequency, temperature, and other environmental factors.
  • To troubleshoot common issues, start by checking the PCB layout and grounding scheme for any potential issues. Ensure that the device is properly biased and that the power supply lines are decoupled. Check for any signs of overheating or thermal issues. If the issue persists, try to isolate the problem by testing individual components or stages of the circuit.
  • To characterize the TCM4-452X+, use a vector network analyzer (VNA) or a spectrum analyzer to measure the device's S-parameters, gain, and noise figure. Use a signal generator to test the device's frequency response and dynamic range. Additionally, use a thermal camera or thermometer to monitor the device's temperature during operation.

Trust Checks

This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

TCM4-452X+ Overview

Use the download button to access the TCM4-452X+ schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TCM4-, or try a keyword search, such as RF Transformers
