Part Image

TCR15AG10,LF - Toshiba

Description: LDO Voltage Regulators

Download TCR15AG10,LF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TCR15AG10,LF - Toshiba PCB footprint - BGA - BGA - TCR15AG10,LF
click to zoom
3D Models
TCR15AG10,LF - Toshiba  - 3D model - BGA - TCR15AG10,LF
click to zoom

TCR15AG10,LF Details

  • Manufacturer Part Number:

    TCR15AG10,LF

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    WCSP-6

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Toshiba America Electronic Components

  • YTEOL:

    6.8

  • Adjustability:

    FIXED

  • Dropout Voltage1-Max:

    0.228 V

  • Dropout Voltage1-Nom:

    0.125 V

  • Input Voltage Absolute-Max:

    6 V

  • Input Voltage-Max:

    5.5 V

  • Input Voltage-Min:

    1.228 V

  • JESD-30 Code:

    R-XBGA-B6

  • Length:

    1.2 mm

  • Line Regulation-Max:

    0.015%

  • Load Regulation-Max:

    0.003%

  • Number of Functions:

    1

  • Number of Outputs:

    1

  • Number of Terminals:

    6

  • Operating Temperature TJ-Max:

    85 °C

  • Operating Temperature TJ-Min:

    -40 °C

  • Output Current1-Max:

    1.5 A

  • Output Voltage1-Max:

    1.018 V

  • Output Voltage1-Min:

    0.982 V

  • Output Voltage1-Nom:

    1 V

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    VFBGA

  • Package Equivalence Code:

    BGA6,2X3,16

  • Package Shape:

    RECTANGULAR

  • Package Style:

    GRID ARRAY, VERY THIN PROFILE, FINE PITCH

  • Regulator Type:

    FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

  • Seated Height-Max:

    0.33 mm

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.4 mm

  • Terminal Position:

    BOTTOM

  • Voltage Tolerance-Max:

    1.8%

  • Width:

    0.8 mm

TCR15AG10,LF Frequently Asked Questions (FAQs)

  • The recommended PCB footprint for TCR15AG10,LF is a 1210 (IEC) or 4532 (EIA) package with a land pattern of 2.5mm x 1.25mm, with a 0.5mm pitch and a 0.3mm keep-out area around the component.
  • To ensure reliability in high-temperature applications, follow proper derating guidelines, use a thermally conductive PCB material, and ensure good thermal conduction between the component and the PCB. Additionally, consider using a thermal interface material (TIM) and a heat sink if necessary.
  • The maximum allowable voltage for TCR15AG10,LF is 15V, as specified in the datasheet. Exceeding this voltage may lead to component damage or failure.
  • Yes, TCR15AG10,LF is suitable for high-frequency applications up to 100MHz. However, it's essential to consider the component's impedance, parasitic inductance, and capacitance when designing the circuit.
  • To handle the ESD sensitivity of TCR15AG10,LF, follow proper ESD handling procedures, use ESD-protective packaging and storage, and implement ESD protection circuits in the design. Additionally, consider using ESD-protected components and PCB materials.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

TCR15AG10,LF Overview

Use the download button to access the TCR15AG10,LF schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TCR15, or try a keyword search, such as Linear Regulator ICs

Parts related to TCR15AG10,LF

Showing 0 results
