TD62784AF - Toshiba

TD62784AF Details

• Manufacturer Part Number:

  TD62784AF

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SOIC

• Package Description:

  0.375 INCH, 1.27 MM PITCH, PLASTIC, SOP-18

• Pin Count:

  18

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0

• Interface IC Type:

  VACUUM FLUORESCENT DISPLAY DRIVER

• JESD-30 Code:

  R-PDSO-G18

• JESD-609 Code:

  e0

• Length:

  12.5 mm

• Multiplexed Display Capability:

  NO

• Number of Functions:

  8

• Number of Segments:

  8

• Number of Terminals:

  18

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  2.45 mm

• Supply Voltage-Max:

  50 V

• Surface Mount:

  YES

• Technology:

  BIPOLAR

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  7 mm
