TDA18218HN - NXP

TDA18218HN Details

• Manufacturer Part Number:

  TDA18218HN

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  QFN

• Package Description:

  7 X 7 MM, 0.85 MM HEIGHT, PLASTIC, MO-220, SOT619-1, HVQFN-48

• Pin Count:

  48

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  0

• Built-in IF Amplifier:

  YES

• Consumer IC Type:

  VIDEO TUNER

• Input Frequency-Max (RF):

  864 MHz

• Input Frequency-Min (RF):

  174 MHz

• JESD-30 Code:

  S-PQCC-N48

• Length:

  7 mm

• Noise Figure-Nom:

  5 dB

• Number of Bands:

  1

• Number of Functions:

  1

• Number of Terminals:

  48

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC48,.27SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1 mm

• Supply Current-Max:

  270 mA

• Supply Voltage-Max (Vsup):

  3.47 V

• Supply Voltage-Min (Vsup):

  3.13 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  7 mm
