TDA4858 - NXP

TDA4858 Details

• Manufacturer Part Number:

  TDA4858

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  DIP

• Package Description:

  0.400 INCH, PLASTIC, SOT-232-1, SDIP-32

• Pin Count:

  32

• HTS Code:

  8542.39.00.60

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  0

• Application:

  MONITOR

• Blanking Output:

  YES

• Consumer IC Type:

  HORIZ/VERT DEFLECTION IC

• JESD-30 Code:

  R-PDIP-T32

• Length:

  28.95 mm

• Number of Functions:

  1

• Number of Terminals:

  32

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SDIP

• Package Equivalence Code:

  SDIP32,.4

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE, SHRINK PITCH

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  4.7 mm

• Supply Voltage-Max (Vsup):

  16 V

• Supply Voltage-Min (Vsup):

  9.2 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.778 mm

• Terminal Position:

  DUAL

• Width:

  10.16 mm
