TDS08 - Apem

TDS08 Details

• Manufacturer Part Number:

  TDS08

• Part Life Cycle Code:

  Active

• Country Of Origin:

  UK

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Manufacturer:

  APEM Inc

• YTEOL:

  6

• Actuator Length:

  0.031 inch

• Actuator Material:

  GLASS FILLED NYLON

• Actuator Type:

  SLIDE TYPE

• Additional Feature:

  UL94V-0 MATERIALS USED

• Body Breadth:

  10.1 mm

• Body Color:

  BLACK

• Body Height:

  5.9 mm

• Body Length or Diameter:

  24.3 mm

• Center Contact Material:

  BRASS

• Center Contact Plating:

  GOLD

• Contact Current(DC)-Max:

  0.025 A

• Contact (DC) Max Rating R Load:

  .025A@24VDC

• Contact Function:

  ON-OFF

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  24 V

• Dielectric Withstand Volts:

  500VDC V

• Electrical Life:

  2000 Cycle(s)

• End Contact Material:

  BRASS

• End Contact Plating:

  GOLD

• Housing Material:

  GLASS FILLED POLYBUTYLENE TEREPHTHALATE

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  GLASS FILLED POLYBUTYLENE TEREPHTHALATE

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Positions:

  8

• Number of Switch Sections:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• PCB Hole Count:

  16

• Packing Method:

  TUBE

• Solderability:

  WAVE

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPST

• Switch Type:

  SLIDE DIP SWITCH

• Terminal Length:

  0.126 inch

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER

• Washability:

  SOLVENT
