TEA2017 - STMicroelectronics

TEA2017 Details

• Manufacturer Part Number:

  TEA2017

• Part Life Cycle Code:

  Active Unconfirmed

• HTS Code:

  8542.39.00.60

• Manufacturer:

  STMicroelectronics

• YTEOL:

  2

• Blanking Output:

  NO

• Consumer IC Type:

  HORIZ/VERT DEFLECTION IC

• JESD-30 Code:

  R-PZIP-T15

• JESD-609 Code:

  e0

• Length:

  19.95 mm

• Number of Functions:

  1

• Number of Terminals:

  15

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  ZIP

• Package Equivalence Code:

  ZIP15,.2,.17TB

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  20.55 mm

• Supply Voltage-Max (Vsup):

  30 V

• Supply Voltage-Min (Vsup):

  10 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  ZIG-ZAG

• Width:

  4.5 mm
