TEN60-4812N Frequently Asked Questions (FAQs)

• What is the recommended input capacitor type and value for optimal performance?
  Traco Power recommends using a low-ESR ceramic or film capacitor with a value of 10-22uF, 50-100V rating, and X7R or X5R dielectric for optimal performance and stability.
• How do I ensure reliable start-up and operation with a high-impedance input source?
  To ensure reliable start-up and operation with a high-impedance input source, Traco Power recommends adding a 1-2uF, 50-100V input capacitor in parallel with the input voltage source to reduce the impedance and improve stability.
• What is the maximum allowed capacitance on the output for stable operation?
  The maximum allowed capacitance on the output for stable operation is 47uF. Exceeding this value may cause oscillations or instability in the converter.
• Can I use the TEN60-4812N in a high-temperature environment, and if so, what are the derating considerations?
  Yes, the TEN60-4812N can be used in high-temperature environments, but derating is necessary. The maximum operating temperature is 80°C, and the output power should be derated by 2.5% per °C above 50°C to ensure reliable operation.
• What is the recommended PCB layout and thermal management for optimal performance and reliability?
  Traco Power recommends a multi-layer PCB with a solid ground plane, and a thermal pad or heat sink for the converter to ensure optimal heat dissipation and performance. A minimum clearance of 5mm around the converter is recommended for airflow and heat dissipation.
