TEP40-3615UIR - Traco Power

TEP40-3615UIR Details

• Manufacturer Part Number:

  TEP40-3615UIR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  1/4 brick package-10

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• Date Of Intro:

  2020-06-09

• Manufacturer:

  Traco Power

• YTEOL:

  7.2

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  EN, IEC, UL

• Efficiency (Main Output):

  90%

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  9 V

• Input Voltage-Nom:

  36 V

• JESD-30 Code:

  R-PDFM-P10

• Length:

  57.9 mm

• Line Regulation-Max:

  0.1%

• Load Regulation-Max:

  0.1%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  10

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  1.67 A

• Output Voltage-Max:

  26.4 V

• Output Voltage-Min:

  19.2 V

• Output Voltage-Nom:

  24 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DFM

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  OUTPUT OVER VOLTAGE; OUTPUT OVER CURRENT; SHORT CIRCUIT; THERMAL

• Ripple Voltage (Main Out):

  0.0707 Vrms

• Screening Level:

  EN 50155; EN 45545-2; IEC/EN/UL 62368-1

• Seated Height-Max:

  13.2 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  40 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.075 s

• Width:

  36.8 mm
