Symbol
PCB Footprints
- Datasheet Download Datasheet
- Stock & Prices $ Price & Stock for TF-109
- Part Number TF-109
- Manufacturer XUNPU
- Pin Count 15
- Part Category Connector
- Package Category Other
- Footprint Name Other - TF-109-3
- Released Date Oct 18, 2019
- Last Modified Date Mar 7, 2023 4:10 PM UTC
- Pinout / Pin List Click Here (Member Only)
TF-109 Details
-
Manufacturer Part Number:
TF-109
-
Manufacturer:
Dongguan Xunpu Electronic Technology Co Ltd
Trust Checks
Expert Contribution
System Verified
Community Approved
TF-109 Overview
Use the download button to access the TF-109 schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like TF-10,
or try a keyword search, such as Thin Film Resistors
