TF31-28S-0.5SH(800) - Hirose

TF31-28S-0.5SH(800) Frequently Asked Questions (FAQs)

• What is the recommended torque for the screw terminals?
  The recommended torque for the screw terminals is 0.5 N·m to 1.0 N·m, as specified in the Hirose Electric Co Ltd's application notes.
• Can I use this connector in high-vibration environments?
  Yes, the TF31-28S-0.5SH(800) is designed to withstand vibrations up to 10 G (10-2000 Hz) and is suitable for use in high-vibration environments, such as in industrial or automotive applications.
• Is this connector suitable for outdoor use?
  The TF31-28S-0.5SH(800) has a rating of IP67, which means it is protected against dust and can withstand immersion in water up to 1 meter for 30 minutes. However, it is not recommended for continuous outdoor use without additional protection, such as a waterproof coating or enclosure.
• What is the maximum operating temperature range for this connector?
  The TF31-28S-0.5SH(800) has an operating temperature range of -40°C to 105°C, making it suitable for use in a wide range of applications, including industrial, automotive, and consumer electronics.
• Can I use this connector with a wire gauge larger than 28 AWG?
  No, the TF31-28S-0.5SH(800) is designed for use with wire gauges of 28 AWG to 32 AWG. Using a larger wire gauge may not provide a reliable connection and may damage the connector.
