Qorvo provides a recommended PCB layout and thermal management guide in their application note AN-2171, which includes guidelines for thermal vias, heat sinks, and PCB stack-up.
Qorvo provides a set of design tools and models, including a biasing and matching network design guide, which can be found on their website. Additionally, Qorvo's application engineers can provide custom design support upon request.
The TGF3020-SM has undergone rigorous reliability and qualification tests, including temperature cycling, humidity testing, and electrical overstress testing, as outlined in Qorvo's reliability report, which is available upon request.
Yes, the TGF3020-SM can be used in non-50 ohm systems. Qorvo provides guidance on impedance matching and de-embedding in their application note AN-2172, which includes examples and design equations.
Qorvo recommends following the standard ESD and moisture-sensitive device handling procedures, as outlined in their packaging and handling guide, which includes guidelines for storage, handling, and baking procedures.
