TJ52UEB2R2MHT - Vishay

TJ52UEB2R2MHT Details

• Manufacturer Part Number:

  TJ52UEB2R2MHT

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  6.7

• Construction:

  Toroidal

• DC Resistance:

  0.0048 Ω

• Inductance-Nom (L):

  2.2 µH

• Inductor Application:

  HIGH CURRENT INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e2

• Lead Diameter:

  1.346 mm

• Lead Length:

  12.7 mm

• Lead Spacing:

  22.86 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  200 °C

• Operating Temperature-Min:

  -55 °C

• Package Diameter:

  25.4 mm

• Package Length:

  14.732 mm

• Package Style:

  Toroidal

• Packing Method:

  Bulk

• Rated Current-Max:

  22 A

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Finish:

  TIN COPPER

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.001 MHz

• Tolerance:

  20%
