TJA1445ATK/0J - NXP

TJA1445ATK/0J Details

• Manufacturer Part Number:

  TJA1445ATK/0J

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  14

• Additional Feature:

  SUPPORTED: ISO 11898-2:2024 A-B; SAE J2284-1 to SAE J2284-5 & SAE J1939-14 compliant

• Data Rate:

  5000 Mbps

• JESD-30 Code:

  R-PDSO-N14

• Length:

  4.5 mm

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  14

• Number of Transceivers:

  1

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVSON

• Package Equivalence Code:

  SOLCC14,.12,25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Peak Reflow Temperature (Cel):

  260

• Screening Level:

  AEC-Q100; ISO 26262-ASIL B

• Seated Height-Max:

  1 mm

• Supply Current-Max:

  125 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Telecom IC Type:

  CAN FD/LIN TRANSCEIVER

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  40

• Width:

  3 mm
