TL1265RGQTCLR - E-Switch

TL1265RGQTCLR Details

• Manufacturer Part Number:

  TL1265RGQTCLR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  E-Switch Inc

• YTEOL:

  7.3

• Actuator Length:

  0.315 inch

• Actuator Travel:

  0.2 mm

• Additional Feature:

  GREEEN & RED BICOLOR LED

• Body Breadth:

  6.8 mm

• Body Height:

  4.6 mm

• Body Length or Diameter:

  7 mm

• Center Contact Plating:

  SILVER

• Circuit Configuration:

  1X1

• Contact Current(DC)-Max:

  0.05 A

• Contact (DC) Max Rating R Load:

  0.05A@12VDC

• Contact Function:

  OFF-(ON)

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  12 V

• Dielectric Withstand Volts:

  500VDC V

• Electrical Life:

  500000 Cycle(s)

• End Contact Plating:

  SILVER

• Illumination:

  GREEN AND RED LED

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Switches:

  1

• Operating Force-Max:

  2.06 N

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• PCB Hole Count:

  6

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  KEYPAD SWITCH

• Terminal Length:

  0.118 inch

• Termination Type:

  SOLDER
