TL2205OABPBB - E-Switch

TL2205OABPBB Details

• Manufacturer Part Number:

  TL2205OABPBB

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.31

• Manufacturer:

  E-Switch Inc

• YTEOL:

  8.1

• Actuator Length:

  0.439 inch

• Actuator Travel:

  2.4892 mm

• Actuator Type:

  PUSHBUTTON

• Body Breadth:

  8.509 mm

• Body Height:

  8.509 mm

• Body Length or Diameter:

  11.811 mm

• Center Contact Plating:

  SILVER

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  0.1A@30VDC

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  30 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  10000 Cycle(s)

• End Contact Plating:

  SILVER

• Illumination:

  LED

• Insulation Resistance:

  100000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• PCB Hole Count:

  8

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  DPDT

• Switch Type:

  PUSHBUTTON SWITCH

• Terminal Finish:

  Silver (Ag)

• Terminal Length:

  0.134 inch

• Termination Type:

  SOLDER
