TLC/5A-102M-00 - Fastron

TLC/5A-102M-00 Details

• Manufacturer Part Number:

  TLC/5A-102M-00

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  FASTRON GmBH

• YTEOL:

  6

• Construction:

  Toroidal

• Core Material:

  IRON DUST

• DC Resistance:

  0.16 Ω

• Inductance-Nom (L):

  1000 µH

• Inductor Application:

  RF INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Lead Diameter:

  1 mm

• Lead Length:

  20 mm

• Lead Spacing:

  30 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  115 °C

• Operating Temperature-Min:

  -55 °C

• Package Diameter:

  83 mm

• Package Length:

  31 mm

• Package Style:

  Radial

• Packing Method:

  Bulk

• Rated Current-Max:

  5 A

• Reference Standard:

  AEC-Q200

• Shape/Size Description:

  CIRCULAR PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.001 MHz

• Tolerance:

  20%
