TLE4972AE35D5XUMA1 - Infineon

Description: Board Mount Current Sensors SPEED & CURRENT SENSORS

Download TLE4972AE35D5XUMA1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TLE4972AE35D5XUMA1 - Infineon PCB footprint - Small Outline Packages - Small Outline Packages - TLE4972AE35D5XUMA1
click to zoom
3D Models
TLE4972AE35D5XUMA1 - Infineon  - 3D model - Small Outline Packages - TLE4972AE35D5XUMA1
click to zoom

TLE4972AE35D5XUMA1 Details

  • Manufacturer Part Number:

    TLE4972AE35D5XUMA1

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    TSOP-16

  • Factory Lead Time:

    39 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    14

  • Body Breadth:

    3.9 mm

  • Body Height:

    1.02 mm

  • Body Length or Diameter:

    5 mm

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output:

    OPEN-DRAIN

  • Output Type:

    ANALOG VOLTAGE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    TSOP16,.2,25

  • Package Shape/Style:

    RECTANGULAR

  • Screening Level:

    AEC-Q100; ISO 26262

  • Sensors/Transducers Type:

    CURRENT SENSOR

  • Supply Voltage-Max:

    3.5 V

  • Supply Voltage-Min:

    3.1 V

  • Surface Mount:

    YES
