Technical Content
Part Image

TLE62512GXUMA3 - Infineon

Description: CAN Interface IC TRANSCEIVER

Download TLE62512GXUMA3 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
TLE62512GXUMA3 - Infineon - PCB symbol
click to zoom
PCB Footprints
TLE62512GXUMA3 - Infineon PCB footprint - Small Outline Packages - Small Outline Packages - TLE62512GXUMA3-+-+
click to zoom
3D Models
TLE62512GXUMA3 - Infineon - 3D model - Small Outline Packages - TLE62512GXUMA3-+-+
click to zoom

TLE62512GXUMA3 Details

  • Manufacturer Part Number:

    TLE62512GXUMA3

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Not Recommended

  • Package Description:

    SOP-14

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00

  • Factory Lead Time:

    26 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    3

  • JESD-30 Code:

    R-PDSO-G14

  • Length:

    8.75 mm

  • Moisture Sensitivity Level:

    2A

  • Number of Functions:

    1

  • Number of Terminals:

    14

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    1.75 mm

  • Supply Voltage-Nom:

    5 V

  • Surface Mount:

    YES

  • Telecom IC Type:

    INTERFACE CIRCUIT

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Width:

    4 mm

TLE62512GXUMA3 Frequently Asked Questions (FAQs)

  • The recommended PCB layout for the TLE62512GXUMA3 can be found in the Infineon application note AN2018-01, which provides guidelines for PCB design, component placement, and thermal management.
  • The TLE62512GXUMA3 can be configured for low-power mode by setting the EN pin to logic low, which reduces the quiescent current to approximately 10 μA. Additionally, the device can be put into standby mode by setting the STBY pin to logic low, which further reduces the quiescent current to approximately 1 μA.
  • The TLE62512GXUMA3 has an operating temperature range of -40°C to 150°C, making it suitable for use in harsh automotive environments.
  • The TLE62512GXUMA3 has built-in overvoltage protection (OVP) and undervoltage protection (UVP) features. The OVP feature limits the output voltage to 18 V, while the UVP feature prevents the device from operating below 6.5 V. Additionally, external protection circuits can be implemented to provide additional protection against voltage transients and surges.
  • The TLE62512GXUMA3 has a maximum output current capability of 2 A, making it suitable for use in automotive applications that require high current handling.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

TLE62512GXUMA3 Overview

Use the download button to access the TLE62512GXUMA3 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TLE62, or try a keyword search, such as Network Interfaces
