TLI4970D050T5XUMA1 - Infineon

Description: Miniature coreless magnetic current sensor for AC and DC measurements with digital interface and fast overcurrent detection

Download TLI4970D050T5XUMA1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TLI4970D050T5XUMA1 - Infineon PCB footprint - Other - Other - TLI4970D050T5XUMA1-2
click to zoom
3D Models
TLI4970D050T5XUMA1 - Infineon  - 3D model - Other - TLI4970D050T5XUMA1-2
click to zoom

TLI4970D050T5XUMA1 Details

  • Manufacturer Part Number:

    TLI4970D050T5XUMA1

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    TISON-8

  • HTS Code:

    8542.39.00.01

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    0

  • Additional Feature:

    SEATED HGT-NOM

  • Analog IC - Other Type:

    ANALOG CIRCUIT

  • JESD-30 Code:

    S-PDSO-N8

  • JESD-609 Code:

    e3

  • Length:

    7 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TSON

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE, THIN PROFILE

  • Seated Height-Max:

    1.05 mm

  • Supply Voltage-Max (Vsup):

    3.5 V

  • Supply Voltage-Min (Vsup):

    3.1 V

  • Supply Voltage-Nom (Vsup):

    3.3 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Matte Tin (Sn)

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    DUAL

  • Width:

    7 mm

TLI4970D050T5XUMA1 Frequently Asked Questions (FAQs)

  • A 4-layer PCB with a solid ground plane and a separate power plane is recommended. Keep the high-frequency components away from the low-frequency components, and use a star-connection for the power supply.
  • Use a heat sink with a thermal resistance of less than 10 K/W. Ensure good thermal contact between the device and the heat sink. Avoid blocking airflow around the device.
  • The maximum allowed voltage on the VCC pin is 5.5V. Exceeding this voltage may damage the device.
  • Use an oscilloscope to check the output voltage and current. Verify the input voltage and current. Check for proper PCB layout and thermal design. Consult the datasheet and application notes for troubleshooting guides.
  • The TLI4970D050T5XUMA1 is rated for operation up to 150°C. However, the device's performance and reliability may degrade at high temperatures. Consult the datasheet and application notes for thermal design considerations.
