TLP3100(F) footprint, schematic symbol and 3D model by Toshiba

Symbol

click to zoom

PCB Footprints

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for TLP3100(F)
Part Number TLP3100(F)
Manufacturer Toshiba
Pin Count 6
Part Category Integrated Circuit
Package Category Small Outline Packages
Footprint Name Small Outline Packages - 11-7C1
Released Date Apr 12, 2022
Last Modified Date Mar 7, 2023 4:10 PM UTC
Pinout / Pin List Click Here (Member Only)

TLP3100(F) Details

Manufacturer Part Number:
TLP3100(F)
Rohs Code:
Yes
Part Life Cycle Code:
End Of Life
Package Description:
SOP-6
HTS Code:
8541.40.95.00
Factory Lead Time:
12 Weeks
Manufacturer:
Toshiba America Electronic Components
YTEOL:
1
Additional Feature:
UL APPROVED
Configuration:
SINGLE WITH BUILT-IN DIODE
Control Current:
0.005 A
Control Voltage:
1.18 V
Forward Current-Max:
0.025 A
Input Type:
DC
Isolation Voltage-Max:
1500 V
Number of Elements:
1
On-State Current-Max:
2 A
On-state Resistance-Max:
0.07 Ω
Operating Temperature-Max:
65 °C
Operating Temperature-Min:
-20 °C
Output Circuit Type:
MOSFET
Overall Height:
2.1 mm
Overall Length:
6.3 mm

TLP3100(F) Frequently Asked Questions (FAQs)

The recommended operating voltage range for the TLP3100(F) is 4.5V to 30V.
The input resistor value depends on the input signal frequency and amplitude. A general guideline is to choose a value between 1kΩ to 10kΩ. A higher value may be required for high-frequency signals.
The maximum output current that the TLP3100(F) can sink is 50mA.
Yes, the TLP3100(F) can be used as a logic inverter by connecting the output to the input through a resistor.
To ensure proper biasing, connect a pull-up resistor between the output and VCC, and a pull-down resistor between the output and GND. The values of these resistors depend on the specific application.

Trust Checks

Community Provided

System Verified

Community Approved

TLP3100(F) Overview

Use the download button to access the TLP3100(F) schematic symbol and PCB footprint.

To find more CAD model downloads similar to this part, try a partial part number search, like TLP31, or try a keyword search, such as Solid State Relays
