TLP3543 - Toshiba

TLP3543 Details

• Manufacturer Part Number:

  TLP3543

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Package Description:

  DIP-6

• HTS Code:

  8541.40.95.00

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0.4

• Additional Feature:

  UL RECOGNIZED

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• Control Current:

  0.005 A

• Control Voltage:

  1.18 V

• Forward Current-Max:

  0.025 A

• Input Type:

  DC

• Isolation Voltage-Max:

  2500 V

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Elements:

  1

• On-State Current-Max:

  4 A

• On-state Resistance-Max:

  0.05 Ω

• Operating Temperature-Max:

  65 °C

• Operating Temperature-Min:

  -20 °C

• Optoelectronic Device Type:

  TRANSISTOR OUTPUT SSR

• Output Circuit Type:

  MOSFET

• Overall Height:

  4.85 mm

• Overall Length:

  7.12 mm

• Surface Mount:

  NO
