TLX9160T - Toshiba

TLX9160T Details

• Manufacturer Part Number:

  TLX9160T

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SO16L-T, 16/12 PIN

• HTS Code:

  8541.40.95.00

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  6

• Additional Feature:

  AEC-Q101

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• Control Current:

  0.005 A

• Control Voltage:

  1.4 V

• Forward Current-Max:

  0.02 A

• Input Type:

  DC

• Isolation Voltage-Max:

  5000 V

• Mounting Feature:

  SURFACE MOUNT

• Number of Elements:

  1

• On-State Current-Max:

  0.05 A

• On-state Resistance-Max:

  250 Ω

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Optoelectronic Device Type:

  TRANSISTOR OUTPUT SSR

• Output Circuit Type:

  MOSFET

• Overall Height:

  2.65 mm

• Overall Length:

  10.3 mm

• Surface Mount:

  YES
