TMLM04109 - Traco Power

TMLM04109 Details

• Manufacturer Part Number:

  TMLM04109

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-7

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• Manufacturer:

  Traco Power

• YTEOL:

  6

• Additional Feature:

  DC INPUT VOLTAGE IS FROM 120 TO 370V

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  72%

• Input Voltage-Max:

  264 V

• Input Voltage-Min:

  90 V

• Input Voltage-Nom:

  100 V

• JESD-30 Code:

  R-PDMA-P7

• Length:

  36.5 mm

• Load Regulation-Max:

  0.5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  7

• Operating Temperature-Max:

  50 °C

• Operating Temperature-Min:

  -25 °C

• Output Current-Max:

  0.444 A

• Output Voltage-Max:

  9.18 V

• Output Voltage-Min:

  8.82 V

• Output Voltage-Nom:

  9 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,7LEAD,.85

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  17.6 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  OTHER

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  4 W

• Trim/Adjustable Output:

  NO

• Width:

  27 mm
